Boat Details


Additional Boat Details

Interior layout

The interior of NAUTORIOUS has been meticulously restored and updated to a condition better than when the boat was new and likely nicer than any other Irwin on the market. Systems, fixtures and finishes have been carefully selected for quality and function as well as aesthetics with a goal of the best possible for the application and conformity with ABYC recommendations. Satin-varnished teak interior woods with traditional teak and holy cabin sole, light colored countertops, overheads and fabric selections contribute to the large, open, well-lit interior spaces (refinished 2008). The Ted Irwin design makes great use of the interior space, providing three cabin, three head boat with a full width salon and an additional cabin/office that feels much larger than other similarly sized boats.
Layout:
Tri-cabin plan includes:
•Aft Owner's cabin with an ensuite Head
•Galley
•Navigation Station
•Full-width Main Salon -- with dinette, breakfast bar and wetbar
•Two Forward Guest Cabins with separate heads
•Additional cabin/office space
•Laundry station
AFT OWNER'S SUITE:
Accessed through the galley on the starboard side, the owner's suite features:
•Centerline queen berth with storage below and two large opening hatches above with retractable shade.
•Integrated drawers and lockers outboard on port and starboard with shelf area above and opening ports on each sides (with curtains for privacy).
•Varnished teak and holly sole with liftouts where needed to access systems below and additional storage
•Large hanging cedar locker to starboard with louvered doors for ventilation and lighting
•Large mirror on aft bulkhead adds to sense of space in cabin
•Built in nightstands on either side of berth with fiddles and lockers below
•New high density 6" memory foam mattresses and custom covers (2012)
•12,000 BTU Cruise Air reverse cycle air conditioning unit for cabin and head
The Owner's Head forward of the cabin to port:
•Raritan Elegance macerator toilet (2009)
•Herreshoff style interior with white bulkheads and counters complemented by varnished teak trim
•Separate shower stall and tub •Opening port for additional natural light and ventilation •Stainless steel sink
•Electroscan Type 1 MSD
•Overboard macerating waste tank pump

Galley

GALLEY:
Large walk through galley to starboard forward of master cabin with abundant counter space and storage:
•White countertops (Formica)
•Double stainless steel sink with single lever hot/cold fixture with pull out sprayer
•Manual fresh water foot pump (2014).
•Seafrost 12v cold plate refrigeration system (both air and water cooled)
•Two fridge compartments for fridge and freezer
•Force 10 3 burner LPG gimbaled stove with oven
•Convection/microwave oven
•Overhead and over-counter lighting
•Opening ports for additional ventilation
•Lockers and shelves outboard above counters
•Additional storage in lockers and drawers under counter and large pantry
•Raised bar forward of sink area with space for seating on forward side
•undersink water tank manifold controls

Electronic Equipment

ELECTRONICS & NAVIGATION EQUIPMENT (2003-2014)
•Furuno Navnet 1934 C Color chartplotter (2 displays, one at helm and one at Nav station) (2003)
•Furuno Navnet 48 Mile open array radar (2003)
•Furuno GP36 GPS (2003) •Furuno Navnet Weather System (2004)
•Furuno depth and sounder meters (2003)
•Furuno AIS system
•Raymarine ST60 wind instruments (2006)
•Raymarine ST60 Tridata (2006)
•Raymarine ST60 Multi repeater at Nav Station (2006)
•5" Aqua Meter Galaxy Compass
•Standard Horizon Matrix AIS+ VHF and hailer (2014)
•Simrad/Robertson AP20 Autopilot with AP21 hand held control (2003)
•USB interfaces at Navstation and Helm Yacht
ENTERTAINMENT ELECTRONICS : (2009)
•Bose 5.1 Surround Sound Lifestyle System (main salon)
•40" Samsung LED flat panel HDTV (on hidden lift in cabinet in main salon)
•KVH TracVision M3DX Satellite antenna and receiver
•Xbox 360 Console
•Powered Glomex terrestrial antenna
•Fusion MS IP500 iPod Sirus/XM radio with remote at helm with Boss 1200 watt amp powering four speakers and subwoofer in cockpit
•Speakers wired to owners cabin and V-berth •Shadow caster LED underwater lights (SCY CC)
•Wireless network
• Glomex powered terrestrial TV antenna

Electrical System

Power:
110/12 volt system
Generator: Kohler 7.5 kw
Wind: Air Breeze (40kW-Hrs/month @ 12 mph)
Solar: 650 Watts

Other Equipment

ENGINE ROOM:
The sound insulated Engine Compartment is easily accessed below the companionway:
•Perkins remanufactured 236.4 85-HP engine with bowman intake manifold (210 hours)
•Engine room lights
•Engine room exhaust fans (2014)
•Fireboy 35VH automatic Halon 1301 system in engine space
•Rebuilt Borg Warner Velvet Drive transmission with 2.57:1 ratio marine reduction gear (210 hours)
•New main engine exhaust system with Vetus fiberglass muffler/mixing elbow/exhaust riser (2014)
•Flexofold three-blade folding propeller
•1 ½"Stainless steel propeller shaft (2014)
•PSS dripless seal (2012)
•New main bearing (2008)
•Spare fixed 3-blade propeller
•Dual Racor filter/water separator for main engine
•Racor filter/water separator for generator
•Oil change pump for main engine and generator (2009)
•Balmar 100 amp alternator with internal and external electronic regulator (2009)
•Raritan 20 gallon 110v water heater with engine heat exchanger
•Surflow Smart Sensor 5.7 Fresh water pump (with spare)
•Dockside pressure regulated water fitting
•Fresh water hoses (2009) •Manual fresh water foot pump in galley (new 2014)
•Splendide 2100 XCP vented washer/dryer (2013)
•wnches
•Rule heavy duty submersible bilge pump with Paragon Jr. float switch below propeller shaft
•Secondary Rule 2,000 GPH bilge pump with float switch mounted above propeller shaft
•Manual bilge pump in galley (picks up from keel bilge area)
•Bronze seacocks throughout boat (replaced 2011-2014)
•(2) Electra Scan Type I treatment units (2014)
•Odor resistant head hoses (2009)
•Holding tank macerating pumpout pumps (2014)
•Emergency tiller steering.
•(2) FRP fuel tanks with a total of 260 US Gallons with supply switching at main panel
•(2) FRP fresh water tanks with a total of approximately 375 US Gallons with supply switching Cruise Air reverse-cycle air conditioning system:
•16,000 BTU system in main salon (2009)
•12,000 BTU system in master cabin aft (2009)
•12,000 BTU system in forward and port guest cabins (2009)
•6,000 BTU system for cockpit (2009)
•Separate digital controls for each unit (2009)
SAILS, SAIL CONTROLS AND RIGGING:
Painted tapered extruded aluminum double spreader mast stepped on keel
•316 Stainless steel dye-form rigging with Norseman fittings
•New Aluminum mast step •Electric Leisure-Furl painted aluminum main boom
•Painted aluminum mizzen boom
•Profurl roller furling headstay.
•Forespar ridged hard vang •Removable inner forestay for staysail
•Harken self tacking system for staysail
•Running backs with tracks for use with staysail and mizzen
•Boom brake
•Rope clutches on mast for genoa and staysail halyards
•Cockpit Rope clutches for leisure furl lines and main boom
•Cockpit Rope clutches for staysail lines
•Spinnaker halyard
•LED foredeck and main spreader lights
•Mizzen deck light

Remarks

NAUTORIOUS is the finest example of the Irwin 52 series afloat in the world today. She has been meticulously maintained and upgraded since she was acquired by her third and current owner in 1990. In addition to her spacious, airy, and comfortable accommodations, she has first class mechanical and sailing systems in excellent condition which have been upgraded and designed for easy and safe shorthanded sailing. In two major refits, in addition to continual improvements, the owner has invested over $450,000 in documented upgrades above and beyond the normal annual maintenance needed to keep NAUTORIOUS in excellent condition. Every system on NAUTORIOUS has been replaced, upgraded, and or refinished to yield a yacht which is superior in all respects to the yacht when new. NAUTORIOUS has a turn of speed which is surprisingly fast for a cruiser or a racer reflecting her Ted Irwin design pedigree. In short, NAUTORIOUS is a joy to sail and cruise and is the ideal yacht for a couple or family interested in day sailing, racing, or long distance cruising and will not fail to please.
SPECIFICATIONS:
Builder: Irwin Yacht & Marine Corp
Designer: Ted Irwin Keel: Centerboard
Rig: Ketch/Removable Inner Forestay
Cockpit: Center
Dimensions:
LOA: 56 ft 0 in
Beam: 15 ft 6 in
LWL: 44 ft 0 in
Length on Deck: 52 ft 0 in
Length Overall: 56 ft 0 in
Minimum Draft: 5 ft 6 in (Board Up)
Maximum Draft: 12 ft 6 in (Board Down)
Displacement: 46500 lbs Ballast: 16000 lbs
Propulsion:
Total Power: 85 HP
Number of Engines: 1
Engine Brand: Perkins (2014 Remanufactured)
Engine Model: 4.236 naturally aspirated diesel
Engine Type: Inboard
Engine/Fuel Type: Diesel
Engine Hours: 210
Propeller: Flexifold 3 blade folding propeller
Drive Type: Direct Drive (Velvet Drive)
Engine Power: 85 HP
Cruising Speed: 7.5 knots @ 1800 RPM
Maximum Speed: 9.6 knots @2200 RPM
Tankage:
Fresh Water Tanks: (375 Gallons) Fuel Tanks: (260 Gallons)
Waste: (100 Gallons)
Power:
110/12 volt system
Generator: Kohler 7.5 kw
Wind: Air Breeze (40kW-Hrs/month @ 12 mph)
Solar: 650 Watts
Accommodations:
Number of single berths: 0
Number of double berths: 3
Number of cabins: 3
Number of heads: 3
Outside Equipment/Extras:
Sidepower Bowthruster
Total Liferaft Capacity: 6 (SWITLICK)
Galley Maid Electric windlass
Hydraulic Dinghy Lift
Deck Washdown
Hot/Cold Swim Platform Shower
Other: (Too Numerous To List Here-See Below)
CONSTRUCTION/PAINT:
•Painted white Topsides with blue cove stripe (2000)
•White Cabin house and deck with painted on nonskid (2009)
•Blue Boot Stripe color (Imron Paint)
•Blue Petite Trinidad bottom paint Construction:
•Hull and keel molded in one piece with integral deck flange
•Hull is foam cored above waterline and solid fiberglass below waterline
•Thru-bolted bronze seacocks on all thru-hulls below waterline (primaries replaced 2013)
•Keel: 16,100 lb. internal lead ballast.
•Centerboard: Reinforced fiberglass. Operates through slot in lead keel.
•Custom balanced semi-skeg mounted rudder with aquamet stainless steel rudder post and mesh (2013).
•Hull has been peeled, rescheduled, and faired to eliminate any blistering and built back with extra laminate schedule and vinylester resin (2000).
•New aluminum Mast step (2005) Deck features include:
•Entire foredeck and side decks have been re-cored with closed cell foam core, the exterior skin replaced using vinylester resin and the entire deck re-painted to a level better than the original condition when new (2005)
•Integrated bowsprit incorporates double anchor roller with stainless steel chafe protection for anchor rode and base for headstay.
•Varnished teak grate on bow pulpit
•Custom welded stainless steel bow and stern pulpits with double lifelines with gates on port and starboard sides and in stern pulpit
•Substantial bulwark for safety and comfort on deck is covered with varnished teak caprail with chafe protection where needed for dock lines
•Cast bronze chocks in bulwarks for bow line and midship dock lines
•(11) opening overhead hatches for exceptional natural light and ventilation (replaced 2005 and rebedded 2014)
•(6) large fixed portlights with custom stainless steel frames allow additional light into main salon (refinished 2009)
•Harken self -tending staysail track on trunk cabin
•Stainless steel mast rail provides support and protection when working at mast
•Varnished teak eyebrow on cabin side
•Varnished teak handrails on cabin top provide additional safety when going forward on deck
•Wide side decks provide easy and safe access forward with ample room on the foredeck, house top and aft deck for relaxing
•Aft deck incorporates large flush fiberglass deck hatch for access to lazarette and room to relax
•Custom remote controlled hydraulic swim platform serves as dinghy lift and adjustable swim platform for easy access on and off the boat at anchor and includes chocks for dinghy storage
•Hot and cold
